Nitrogen Gas Generators are available using the PSA Technology as well as the newer KOH Electrolyte based Membrane Separation Technology. Both the technologies have thier distinctive uses with the PSA systems being the industry standard and the newer membrane technology being more widely used now due to the lower prices with development of the technology on a nano scale.Nitrogen Gas Generators from sam gas plants use PSA or Membrane design that ensures that all the Nitrogen Gas Generator are safe, flexible, reliable, and cost effective solutions. Nitrogen Gas Generators have wide variety of industrial and process applications.
| Type of systems | PSA & Membrane separation |
| Purity levels | 99.0 to 99.9995% depending upon the technology and model |
| Flow Rates | From 500 ml/min to 2 LPM for Membrane based systems |
| From 500 ml/min to 10 LPM for PSA based systems | |
| Pressure | 65 PSIG for Membrane based systems |
| 75 PSIG for PSA based systems | |
| Type Of Compressor | Oil free wobble free from Germany which can be mounted inside or externally in a separate enclosure depending upon the system capacity. |
| Nitrogen Storage Volume | From 50 Liters to 150 Liters depending upon the model selected |
| Size of the Systems | Compact table top models for Membrane based systems Under table systems or miniature table top models for PSA based systems with castors for easy maneuverability |
| Noise | Silent systems for Membrane based systems with noise less than 40 dB. |
| 45 dB to 70 dB dependence upon the model selected for PSA based gas generator systems with castors for easy maneuverability | |
| Start Up Time | 15 minutes to 2 hours depending on the model selected |
| Power Supply | 230V AC, 50 Hz, Single phase |
| Weight | 22 kgs to 215 Kgs depending upon the model selected |
